Product Detail

Description

Technical data

Fiber Count	Cable Dimension	Cable Weight	Tensile		Crush		Min. Bend Radius		Range of Temperature
	(mm)	(kg/km)	(N)		(N/100mm)		(mm)		(℃)
			Long Term	Short Term	Long Term	Short Term	Dynamic	Static
2	3.2	8.5	80	150	200	1000	20D	10D
2	3.8	11.5	100	200	200	1000			-20~+60
2	4.5	15.2	150	300	200	1000
2	5	17.5	200	400	200	1000
Note: 1. All the values in the table, which are for reference only, are subject to change without notice;
2. D is outer diameter of the round cable;
3. The min bend radius (static) is 5D when G.657 fiber is used.

Main mechanical & environmental performance test

Characteristic	Characteristic	Characteristic	Characteristic
Optical properties
Attenuation	1310nm 1550nm 1625nm	≤0.35 ≤0.21 ≤0.23	dB/km dB/km dB/km
Attenuation Value	1310～16250nm	≤0.035	dB/km
Difference attenuation between	1285～1310nm 1310nm 1525～1575nm 1550nm 1480～1580nm 1550nm	≤0.03 ≤0.02 ≤0.04	dB/km dB/km dB/km
Macro bending sensibility	@1550nm @1625nm @1550nm @1625nm	≤0.25 ≤1.0 ≤0.75 ≤1.5	Radius 15mm, 10 circle Radius 15mm, 10 circle Radius 10mm, 1 circle Radius 10mm, 1circle
Zero dispersion wavelength		1300～1324	nm
A zero-dispersion slope		≤0.092	ps/(nm².km)
dispersion conefficient	@1285-1340nm @1550nm @1625nm	-3.4-3.4 ≤18.0 ≤22.0	ps/(nm².km)
Cable cut-off wavelength（λcc）		≤1260	nm
Mode field diameter （MFD）	1310nm 1550nm	8.4-9.2 9.3-10.3	μm μm
Attenuation discontinuities	1310nm 1550nm	≤0.05 ≤0.05	dB dB
Geometric characteristics
Core diameter		0.7	μm
Cladding Diameter		125±0.7
Cladding roundness		≤0.7	%
Coating diameter		245±7	μm
Coating / packagae concentricity error		≤12.0	μm
Core / package concentricity error		≤0.5	μm
The warpage (radius)		≥4	m
Environmental characteristics（1310nm、1550nm、1625nm）
Temperature additional attenuation	-60℃ ～+85℃	≤0.05	dB/km
Temperature-humidity cycle additional attenuation	-10℃ ～+85℃，85% Relative humidity, 30 days	≤0.05	dB/km
Flooding additional attenuation	23℃，30 days	≤0.05	dB/km
Hot and humid additional attenuation	85℃和85% Relative humidity，30 days	≤0.05	dB/km
Dry heat aging	85℃	≤0.05	dB/km
Mechanical properties
Screening tension		100kpsi, 1% strain	N
