Cur síos
Sonraí teicniúla| Snáithín Count | Toise Cábla | Meáchan Cábla | Tensile | Crush | Min. Ga ga | Raon Teochta | |||
| (mm) | (kg / km) | (N) | (N / 100mm) | (mm) | (℃) | ||||
| Fadtéarmach | Ghearrthéarma | Fadtéarmach | Ghearrthéarma | Dinimiciúla | Statach | ||||
| 2 | 3.2 | 8.5 | 80 | 150 | 200 | 1000 | 20D | 10D | |
| 2 | 3.8 | 11.5 | 100 | 200 | 200 | 1000 | -20 ~ + 60 | ||
| 2 | 4.5 | 15.2 | 150 | 300 | 200 | 1000 | |||
| 2 | 5 | 17.5 | 200 | 400 | 200 | 1000 | |||
| Nóta: 1. Tá na luachanna uile sa tábla, atá le haghaidh tagartha amháin, faoi réir a n-athraithe gan fógra; | |||||||||
| 2. Is é D seachtrach an chábla bhabhta; | |||||||||
| 3. Is é 5D an ga lúbtha (statach) nuair a úsáidtear snáithíní . | |||||||||
Príomhthástáil feidhmíochta meicniúil agus comhshaoil
| Saintréith | Saintréith | Saintréith | Saintréith |
| Airíonna optúla | |||
| Méadú | 1310nm 1550nm 1625nm |
≤0.35 ≤0.21 ≤0.23 |
dB / km dB / km dB / km |
| Luach Méadaithe | 1310 ～ 16250nm |
≤0.035 |
dB / km |
| Difríocht tanúcháin idir | 1285 ～ 1310nm 1310nm 1525 ～ 1575nm 1550nm 1480 ～ 1580nm 1550nm |
≤0.03 ≤0.02 ≤0.04 |
dB / km dB / km dB / km |
| Íogaireacht lúbthachta macra | @ 1550nm @ 1625nm @ 1550nm @ 1625nm |
≤0.25 ≤1.0 ≤0.75 ≤1.5 |
Ga 15mm, 10 ciorcal Ga 15mm, 10 ciorcal Ga 10mm, 1 chiorcal Radius 10mm, 1circle |
| Tonnfhad scaipthe nialais | 1300～1324 | nm | |
| Fána scaipthe nialas | ≤ 0.092 | ps / (nm 2 .km) | |
| comhéifeacht scaipthe | @ 1285-1340nm @ 1550nm @ 1625nm |
-3.4-3.4 ≤18.0 ≤22.0 |
ps / (nm 2 .km) |
| Tonnfhad scoite cábla（ λ cc） | ≤ 1260 | nm | |
| Mode field Trastomhas （MFD） | 1310nm 1550nm |
8.4 -9.2 9.3-10.3 |
μm μm |
| tanúcháin neamhleanúnachais | 1310nm 1550nm |
≤ 0.05 ≤ 0.05 |
dB dB |
| Saintréithe geoiméadracha | |||
| Trastomhas croí | 0.7 | μm | |
| Trastomhas Cumhdaigh | 125± 0.7 | ||
| Babhta cumhdaigh | ≤ 0.7 | % | |
| Coating Trastomhas | 245± 7 | μm | |
| Sciath / Packag a e earráid concentricity | ≤ 12.0 | μm | |
| Core / pacáiste earráid concentricity | ≤ 0.5 | μm | |
| Tá warpage ( ga) | ≥4 | m | |
| Saintréithe comhshaoil （1310nm 、 1550nm 、 1625nm） | |||
| Teocht tanú breise | -60 ℃ ～+ 85 ℃ | ≤ 0.05 | dB / km |
| Timthriall teocht-taise maolú breise | -10 ℃ ～+ 85 ℃ ， 85% Bogthaise choibhneasta , 30 lá | ≤ 0.05 | dB / km |
| Méadú tanú breise | 23 ℃ ， 30 lá | ≤ 0.05 | dB / km |
| Méadú tanú breise | 85 ℃ 和 85% Bogthaise choibhneasta ， 30 lá | ≤ 0.05 | dB / km |
| Teas tirim ag dul in aois | 85 ℃ | ≤ 0.05 | dB / km |
| Airíonna meicniúla | |||
| Screening tension | 100kpsi, brú 1% | N. | |
|
